UHT Tube Sterilizer & Fruit Juice Sterilization Machine

FOB Reference Price:Get Latest Price
  • 1 - 2 Sets
    US $45000.00
  • >=3 Sets
    US $44000.00
Report Suspicious Activity
Overview
Quick Details
Processing:
Sterilizer
Condition:
New
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
YINZHOU
Model Number:
YZ-TG-0.5
Processing Types:
Juice
Voltage:
380V
Power(W):
10KW
Weight:
1000kg
Dimension(L*W*H):
3500*1600*1500 Mm
Certification:
CE/ ISO9001
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Application:
juice, jam, sauce and other liquid beverages
Type:
Tubular
Material:
Stainless Steel 304
Capacity:
Different Capacity
Sterilization ways:
Tubular Ultra-High Temperature
Sterilizaiton control:
SIMENS
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden case
Port
Shanghai
Lead Time :
45 days
Product Description

Sterilizer for fruit juice, jam, vegetable juice, milk...

Which is divided into two types: Tubular sterilizer & Casing sterilizer
Tubular sterilizer is applicable to beverages which is good fluidity and less solid particle, such as tea, milk, juice,etc. And casing sterilizer applies to filling high viscosity materials, such as jam, fruit paste. Compared to tubular sterilizer, the casing sterilizer has a wider range of application. Whether materials are high viscosity or low viscosity, it is applicable. And for progressing high-solid materials, it is more applicable.


Structure:
Tubular sterilizer: in the largest tube, there are many fine tubes next to each other. Material flows from this fine tubes, and hot water flow through gaps between tubes. The function of sterilization is realized by the superheated water. (the temperature is over 100 degrees.)
casing sterilizer: there are four varisized tubes, they are one inside the other. Except material flow through second tube from the outside, and other tubes flow by superheated water.


Production Features
1.stainless steel SUS 304 material besides motors, electrical appliances, soft connections.
2.Bring in CIP/SIP system, sterilizing pipes do aseptic treatment at high temperature for 125 degrees before production and after sterilization.
3.The control system composed by human-computer interface and PLC, easy to operate.
4.Sterile protection for pipe joints and connection points, strictly guarantee product quality.
5.Bring in heat recovery system, energy saving more than 30% the same industry.
6.The overall design has better pass efficency, can ensure the flow speed and heating time of the viscous materials.
7.The main team valve of our equipment is SpiraySarco brand and the main electrical equipment is SEIMENS brand.

Company Introduction

YINZHOU MACHINERY is a professional fruit & vegetable juice and jam equipment processing enterprise. We specialize in the research, development, design, manufacture and turnkey project of fruit and vegetable processing, concentrated juice jam and tea beverage.

Main Products including Fruit and vegetable pre-treatment equipment, juicing equipment, preheating equipment, filtration and separation equipment, vacuum enrichment equipment, tube and casing sterilization equipment, large bag aseptic filling equipment, BIB bag in box aseptic filling equipment, packaging and sealing equipment, CIP cleaning equipment. Hot products are tubular sterilizer, large bag aseptic filling equipment and BIB bag in box aseptic filling equipment.

Our company can provide daily processing 20-1500 tons of the original fruit of the entire production line according to customer needs. Our machines have already been exported to all over the world including the Asian countries, Middle East coutries, African countries, South American countries and even European countries. And its current sales network and after-sales service network has covered domestic and foreign markets.

Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
4500 (L) * 2500 (W) * 2000 (D)
Weight
2800kg



Packaging Details
The normal package is wooden case(Size: L*W*H). If export to european countries,the wooden case will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
FAQ

[Q]: Are you a manufacturer or a trade company?
A : We are a fruit & vegetable equipment  processing  factory, we market our own products.
[Q]: Does the machine / equipment difficult to install?
A: We will install and debug well for the machine before delivery. Moreover, we will send engineers to your factory to install and debug the machines. And we will also teach your employees how to use the machines untill they are proficient in operating.
[Q]: Can you provide customized products?
A :Yes, we can design and manufacture machines according to customer’s requirements.

[Q]: What is the package of this machine? Will it damage during shipment?
A: Machines will be packed in standard wooden case. So it will not damage. After you receive our machines, you can check wether it is OK.
[Q]: What si the warranty?
A: It is one year warranty (except for artificial damaged).
